In this episode of fire fundamentals with the ITB fire resistance expert Piotr Turkowski we break down what a fire resistance rating criteria, and what the letters behind ratings like “REI 60” exactly stand for. We use lab experience to explain where the standards are clear, where they are oddly traditional, and where comparisons between products can mislead.

• ISO definition of fire resistance as an ability over time
• What R E I W and M mean in fire resistance classification
• Load bearing capacity as deformation and collapse criteria
• How test loads are applied and why load choice matters
• Integrity E as flames and openings rather than smoke tightness
• Cotton pad test and why it blurs integrity versus insulation
• Insulation I temperature rise limits and prescribed thermocouple points
• Radiation W as a heat flux limit and when it matters
• Mechanical impact M and the wrecking ball style verification
• Why fire resistance time does not add up across layers
• Furnace minutes, strict thresholds, and unknown test uncertainty

If you liked this podcast episode, you will definietely enjoy:


----
The Fire Science Show is produced by the Fire Science Media in collaboration with OFR Consultants. Thank you to the podcast sponsor for their continuous support towards our mission.

00:00 - Why Fire Resistance Still Confuses

04:40 - A Working Definition Of Fire Resistance

07:40 - R Criteria And Deformation Limits

16:10 - How Test Loads Get Chosen

25:00 - Integrity E Flames Cracks Cotton

30:53 - Insulation I Temperatures And Thermocouples

40:50 - Radiation W And What It Adds

44:58 - Mechanical Impact M Wrecking Ball Test

50:45 - Why Ratings Do Not Add Up

55:30 - The Clock Rules And Uncertainty

58:37 - Key Takeaways And What Comes Next

WEBVTT

00:00:06.080 --> 00:00:06.290
​Hello everybody.

00:00:06.290 --> 00:00:07.549
Welcome to the Fire Science Show.

00:00:07.549 --> 00:00:11.448
Last week we had a little laugh, uh, with the April Fools.

00:00:11.448 --> 00:00:21.483
it appears that when you have a podcast on Wednesdays, it's that easy to target April Fools Day with it, and the next is probably more than 10 years away.

00:00:21.483 --> 00:00:24.347
So I had to squeeze something out of it.

00:00:24.347 --> 00:00:30.077
This week we're back to good old fire science, and in this episode we will be discussing.

00:00:30.077 --> 00:00:33.627
Fire resistance with my good colleague from the office.

00:00:33.627 --> 00:00:34.045
Piotr Turkowski.

00:00:34.045 --> 00:00:42.127
Fire resistance is something that if you are a fire you will work with it, period.

00:00:42.127 --> 00:00:43.746
There is no escape.

00:00:43.746 --> 00:00:47.133
There is no chance you will not be exposed to it.

00:00:47.133 --> 00:00:49.773
Uh, at some point of doing your design.

00:00:49.773 --> 00:00:55.097
Probably doing it literally all the time because work.

00:00:55.097 --> 00:01:04.697
This is something that is just, uh, being used to assess the structural fire engineering, or this is something as a proxy of structural fire engineering.

00:01:04.697 --> 00:01:07.308
Perhaps that's the better way to, to put it.

00:01:07.308 --> 00:01:08.171
And, um.

00:01:08.171 --> 00:01:15.596
For fire resistance, there are multiple components that you have to take into account to understand what it fully means.

00:01:15.596 --> 00:01:19.197
One would be the element and how the element is designed.

00:01:19.197 --> 00:01:25.706
What materials are being used, what are the properties of the material, different elements, different uh, kinds of.

00:01:25.706 --> 00:01:30.453
Specimens will go through a slightly different variations of the fire resistance test.

00:01:30.453 --> 00:01:31.805
We're not talking about that today.

00:01:31.805 --> 00:01:34.287
The second aspect is thermal exposure.

00:01:34.287 --> 00:01:36.628
What type of curve you are using.

00:01:36.628 --> 00:01:39.837
We're also not talking about that today that much.

00:01:39.837 --> 00:01:41.474
The third one would be the furnace.

00:01:41.474 --> 00:01:44.055
What kind of furnace are you using?

00:01:44.055 --> 00:01:49.518
And and there are actually nuanced differences between furnaces in the world.

00:01:49.518 --> 00:02:00.768
However, a lot of effort was put into mitigating those, so, the far resistance on different furnaces in different is somewhat comparable.

00:02:00.768 --> 00:02:03.283
And we're also talking about that today.

00:02:03.283 --> 00:02:19.393
The thing that we're talking about today are the criteria the assessment, the criteria of the fire resistance So what actually is being assessed when a specimen is given a rating when your specimen gets REI 60?

00:02:19.393 --> 00:02:22.883
What does that exactly mean?

00:02:22.883 --> 00:02:27.771
And you could imagine, you could say, uh, yeah, R is load is integrity.

00:02:27.771 --> 00:02:28.973
I is installation.

00:02:28.973 --> 00:02:29.842
That's it.

00:02:29.842 --> 00:02:35.673
But as everything in the world of fire science or fire when you go deep.

00:02:35.673 --> 00:02:43.736
It gets complicated and messy and you find a hundred years stuff that probably should not be there today.

00:02:43.736 --> 00:03:00.358
And yeah, it's, it, it, it's fun and, uh, such as the world fire resistance, uh, criteria, which we are delving into So yeah, please join me in OT in this Fire Fundamentals Let's spin the intro and jump into the episode.

00:03:00.358 --> 00:03:28.323
The Fire Science Show podcast is brought to you in with OFR Consultants.

00:03:28.323 --> 00:03:38.174
OFR is the UK's leading independent multi-award winning fire engineering consultancy with a reputation for delivering safety driven solutions.

00:03:38.174 --> 00:03:47.353
we've been on this journey together for three years so far, and here it begins the fourth year of collaboration between the Science Show and the OFR.

00:03:47.353 --> 00:04:04.929
So far, we've brought you more than 150 episodes, Which into nearly 150 hours of educational content available, free, accessible, all over the planet without any paywalls or hidden agendas.

00:04:04.929 --> 00:04:11.739
This makes me very proud and I am super thankful to OFR for long lasting partnership.

00:04:11.739 --> 00:04:35.357
I'm extremely happy that we've just started the year four, I hope there will be many years after that to come So big OFR for your support to the Fire Science show and the to the fire safety community at large that we can And for you, the listener, if you would like to learn more or perhaps even become a part of OR, they always have awaiting.

00:04:35.357 --> 00:04:39.826
Check their website@orconsultants.com And now to the episode.
